Exceptional Performance
Flexible, easy installation
A single Cable connects the Windows Compute to the Touch Console with an additional UC S07 Videobar. The Kit also helps to facilitate the switch to Microsoft Teams Rooms Smart Spaces for BYOD scenarios, enhancing Teams-native audio and video experiences while accommodating cost-balancing needs.
A reliable and certified choice
The MAXHUB XT10-VB kit has undergone a series of stringent Microsoft compatibility and certification processes. It comes with a 3-year advanced replacement warranty and local support, ensuring a seamless user experience and uninterrupted workflow for Microsoft Teams Rooms while accommodating cost-balancing needs.
MAXHUB is one of the largest global one-stop UC endpoint hardware providers for hybrid collaboration meeting solutions, including high-quality display and UC equipment. Our solutions seamlessly integrate with existing meeting systems, unlocking the full potential of boundless collaboration.
Technical Specifications
Product Specification
Type
Mini-PC
CPU
12th Gen Intel i3
Memory
8GB DDR4 3200MHz SO-DIMM x 2
Storage
128GB SATA SSD (M.2-2280 SATA3 up to 6Gb/s)
Graphics
Intel® UHD Graphics for 12th Gen Intel® Processors
Network
1000Mbps RJ45
Operating System
Windows 11 IoT Enterprise SAC
Application
Microsoft Teams Room
I/O Port
USB-A 3.0
4
LAN
1
USB-C (for Teams Rooms Console)
1
HDMI Out
1
Audio Out
1
AC Power
1
Kensington Lock Slot
1
Power
Power Supply Mode
AC POWER
Power Requirements
100-240V AC 50/60Hz
Max Power
90W
Accessories (included in the Package)
Wall Bracket
×1
PC Bracket
×1
Cable Cover
×1
HDMI Cable (1.8m/5.9ft)
×1
Power Cord (1.8m/5.9ft)
×1
Quick Start Guide
×1
Physical Specification
Product Dimension
230 × 185 × 41.5 mm / 9.06 x 7.28 x 1.63 inch
Product Weight
1.36 kg / 3 lbs
Display
Size
10.1 inch
Resolution
1920 (H) x 1200 (V)
Frequency Refresh Rate
60Hz
Back Light Unit
ELED
Brightness with Glass
Min.250cd/m², Typ.300cd/m²
Life Time
≥ 20000 Hours
Touch System
Type
Capacitive touch
Surface Treatment
Anti-fingerprint, Anti-glare
I/O Port
HDMI In (Content Sharing)
1
USB-A 2.0 (Table Audio Devices)
1
USB-C 3.1 (for Connection to XC13T Mini PC)
1
Audio Out (Headphone, w/o mic)
1
Sensor
Motion Sensor
PIR sensor for auto wake-up
Accessories (included in the Package)
USB Type-C Cable (Type C-C) 5m / 16.4ft
×1
HDMI Cable 1.8m / 5.9ft
×1
Quick Start Guide
×1
Physical Specification
Product Dimension
245 × 164.3 × 77.4 mm / 9.65 x 6.47 x 3.05 inch
Product Weight
0.88 kg / 1.94 lbs
Camera
Pixel
12M
Sensor
1/2.3-inch 12MP Sony sensor
ZOOM
5x Digital Zoom
Output Format
MJPG; YUY2; H.264
Field of View
120° (D)
Adjustable Angle
± 15° (V)
Focus Mode
Fixed-Focus
Focus Distance
1m
Special Features
Auto Framing: automatic adjustment FOV to fit all participants
Speaker Tracking: voice triggered people tracking
10 Zooming Pre-sets for instant setting up
Power
Power Requirements
12V
Overall Power(Max.)
10W
PoE Power
Yes (IEEE 802.3af or 802.3at)
Audio
Speaker
Sound Chanel
1.1
Output Power
8W + 3W
Maximum Sound Pressure
80dBSPL@1m
Signal-to-Noise Ratio
>75dB
Frequency Range
150Hz ~ 18kHz
Microphone
Microphone Quantity
6
Voice Pickup Range
8m
Microphone Frequency Range
100Hz ~ 7.5kHz
Special Features
Noise Reduction
Echo Cancellation
Anti-Reverberation
Built-in AGC Algorithm
Input/Output Port
USB 3.0 Type-C
Connect USB host, upgrade system, etc.
Audio Out
Used for external audio equipment
DC 2.0
Used for 12V power input power supply
RJ45
No IP Support, only provides PoE power
Compatibility
Support major VC software including ZOOM, Microsoft® Teams, Google Meet, Google Hangouts, Cisco WebEx®, RingCentral, etc.
System Requirements
Supports Windows XP/7/8.1/10/11, Android 8.1 or higher, and MAC OS 10.12 or higher
Mount
Wall-mounted
TV mount kit (Optional)
Warranty
3-year hot swap
Accessories one year
What’s in the Box
included
1 x USB C-A Cable (1.8m / 5.9 ft), 1 x Remote Control
1 x Power Adapter, 1 x Wall-mounted Components, 1 x Camera Privacy Cover
